SENECA Z-4TC輸入模塊,Z-4TC輸入模塊
SENECA Z-4TC輸入模塊,Z-4TC輸入模塊產品資料:
意大利SENECA Z-4TC輸入模塊參數特點:
Order code : | Z-4TC | |
Description: | 4-CH thermocouple input module / RS485 | |
Power supply: | 10..40 Vdc; 19..28 Vac (50-60 Hz) | |
Transducers supply: | 20 Vdc, 20 mA | |
Dimensions: | 17,5 x 100 x 112 [mm] | |
Mounting: | DIN 46277, 35 mm symmetrical rail | |
Input: | 4-CH bipolar voltage ±80 mV or thermocouples type J,K,R,S,T,B,E,N | |
Resolution: | 14 bit + sign | |
Communication: | RS485 2 wire, ModBUS RTU slave protocol |
